The Radiator Core Structure
The radiator core is the most important part of the radiator,. The radiator core is composed of tubes, fins and upper and lower main fins. Because it has sufficient heat dissipation area, it can ensure that the engine heat can be dissipated to the atmosphere.And the radiator core is made of extremely thin metal and its alloy with good thermal conductivity, which can make the radiator core achieve the highest heat dissipation effect with the smallest quality and size. There are many types of radiator core structures, as shown in the below: tube and fin type, tube strip type, cell type, tube core type and so on.
a. Tube slice b. Tube belt c. Cellular d. On-die
