Oil Filter 1-87810059-0 Equivalent to PT466 P550059 LF3422 4505384 For Hitachi,Isuzu,TCM Equipment.
Oil Filter 1-87810059-0 Equivalent to PT466 P550059 LF3422 4505384 For Hitachi,Isuzu,TCM Equipment.
Cross Reference:
Baldwin PT466 Donaldson P550059 Fleetguard LF3422OEM Part Number:
1-87810059-0Brand:
AYREST/Authorized BrandMinimun Order Quantity:
60pcsEX.W Price:
The price base on your quantityKnowledge points
What is the structure of Oil Filter 1-87810059-0?
The Oil Filter 1-87810059-0 is designed with a specific structure to effectively filter and clean the oil in an automotive system. It typically consists of a cylindrical metal housing with threaded connections for easy installation and removal. The design also incorporates an anti-drainback valve, which prevents oil from draining back into the engine when the vehicle is not running, ensuring immediate lubrication upon engine startup.
Inside the housing, the Oil Filter 1-87810059-0 contains a filtering element made of a paper or synthetic media. This filtering element effectively traps and removes contaminants, such as dirt, metal particles, and sludge, from the engine oil as it flows through the filter. It also has a bypass valve that allows oil to flow freely in case the filter becomes clogged, preventing engine damage and ensuring continuous lubrication.
The oil enters the filter through an inlet, and the filtered oil exits through an outlet, which is connected back to the engine. The structure of the Oil Filter 1-87810059-0 is designed to ensure proper filtration, efficient oil flow, and reliable performance in automotive applications.
Details
Part Number:1-87810059-0
Part Type:Oil Filter
Brand:Isuzu
MOQ:60pcs
Producing area:Jiangxi,China
Certification:ISO9001,CE,ISO14001,OHSAS18001
Price:Negotiable
Payment term:TT,LC
Payment:T/T 30% as deposit,and 70% before delivery
Packaging Details:Carton
1-87810059-0 Specification:
| Outer Diameter | 104 mm (4.09 inch) |
| Inner Diameter | 50 mm (1.97 inch) |
| Length | 232 mm (9.13 inch) |
1-87810059-0 OEM Cross Reference:
Baldwin PT466
Donaldson P550059
Fleetguard LF3422
Hifi SO 6166
Sakura O-1506
Hitachi 4178560 4505384 4545384
Isuzu 1878100590 1878100650 9132400480 9132400670 9132400680 9132400700 9132401070 9881322651 9885132650 9885132651 9885132652 9885132653 1878100591
Link-Belt 3H1752
Micro 6166 O6166
Nkk 4ID107
Vic 555
1-87810059-0 Application:
HITACHI
E10 UH06 UH121 UH171 UH181
ISUZU
E120 6RB2 6QA2 6RA1T E120H E120T DH100H 4JB1 6RA1 6QA1
KATO
HD1100G
TCM FD180 FD200L FD250L
